SKU: 30502012701

XRotor H60A 14S BLDC

Brushless ESC with BLDC drive, specialized designed for UAV drones. BLDC performs better compatibility and stability in driving. Supports CAN & PWM dual throttle, better resist external electromagnetic interference. New Generation Black Box Feature, allowing millisecond-level data recording and fast data & fault analyzing. Adopts CAN 2.0 Communication Technology, the working status of the ESC can be remotely monitored in real-time through the flight controller, and the thrust system data can be accurately diagnosed and analyzed.

74,29

40 en stock

Payment methods

Technical specifications

Weight: 67g (without cable)
Battery: 6-14S
IPC function: Not available
Size: 78.5*32.5*18.4mm
Fail storage: LOG+FAULT
THR pulse: 1100-1940μs
Communication Protocol: CAN+PWM
Max current: 60A (3s)
Cont current: 40A

More Details
