XRotor H100A 14S FOC V1

Description

Brushless ESC for industrial UAV drones, featuring FPC driving, precise and efficient. FOC Intelligent drive vector control has higher efficiency, lower temperature, faster response, lower noise, lower interference, linear throttle, precise control, and kinetic energy recovery. IPC (Intelligent Propeller Control) version is optional, allowing flexibly stop propellers at a preset or fixed angle. Protection level IP55 (customizable IP67). The ESC has its own fault storage function for fault analysis, allowing fast data transmission and real-time acquisition of key information such as ESC status, speed, throttle, current, voltage.

More Information

Battery: 12~14S
IPC function: Customization required
Size: 83*59*27.4mm
Fail storage: FAULT
THR pulse: 1100-1940μs
Communication Protocol: CAN+PWM
Max current: 120A (3s)
Cont current: 40A
