Hobbywing XRotor X9 Plus Integrated Propulsion System

The Hobbywing XRotor X9 Plus is an upgraded propulsion system built for industrial and agricultural drones, delivering higher thrust, better efficiency, and robust durability. With IPX6 waterproofing, advanced cooling, and intelligent safety protections, it is optimized for heavy-duty UAV applications.

Key Features

Powerful Heavy-Lift Performance

• Maximum thrust: 26.5 kg per axis (with 36″ composite folding propellers)

• Recommended load: 11–13 kg per axis for best efficiency

• Supports 20L-class agricultural drones with MTOW of ~50–60 kg

Integrated Motor + ESC Design

• Large-load Hobbywing 9-series motor with FOC algorithm optimization

• ESC and motor combined into one lightweight module for easy installation

• Compatible with 40 mm circular carbon fiber tubes

Robust & Durable Construction

• IPX6 waterproof, dustproof, and corrosion-resistant design

• Collision-proof motor seat reduces damage during crashes

• Engineered for long-term reliability in harsh agricultural environments

Efficient Cooling System

• Enlarged air duct improves active cooling under high-power load

• Lower current and reduced heat ensure longer service life

Smart Safety & Monitoring

• Built-in protections: power-on self-test, voltage abnormality, current, and stall protection

• Real-time output to flight controllers: throttle, motor speed, voltage, current, phase current, capacitor, and MOSFET temperatures

• Navigation lights with fault indication for quick troubleshooting

Data & Upgrade Support

• Compatible with Hobbywing DataLink (sold separately) for closed-loop monitoring of up to 8 power systems

• Firmware updates supported via DataLink for continuous optimization

*Propellers are sold separately
