C8020-210KV-IPC

Hobbywing C8020 Fixed-Wing Drone Motor

The Hobbywing C8020 is a heavy-duty fixed-wing UAV cruise motor designed for superior reliability in demanding electric fixed-wing and VTOL applications. Part of the C-series 80XX family, it delivers the robust performance and exceptional durability required for professional UAV cruise operations.

Key Features

High-Thrust Fixed-Wing Performance

• 80mm stator diameter for high-power output
• Designed for fixed-wing UAV cruise and VTOL applications
• Supports both tractor and pusher propeller configurations
• Compatible with HOBBYWING IPC (Intelligent Propeller Control) ESC

Innovative Magnetic Circuit & Cooling Design

• Proprietary magnetic circuit design for optimized drive parameter matching
• Rectangular rotor bracket outlet reduces airflow resistance and improves heat dissipation efficiency by 20%
• Triple-bearing system for optimal dynamic balance and impact resistance

Industrial-Grade Durability

• Validated through Drive Performance Validation (DPV), Water Ingress Testing, Salt Spray Test, Mechanical Stress Testing, and Tri-Comprehensive (Temperature, Humidity, Vibration) Test
• 1,000-hour laboratory fatigue life validation
• Premium 0.2 mm silicon steel cores, 220°C enameled wires, and high-grade curved magnetic tiles

Versatile Propeller System

• Detachable propeller adapter with anti-slip, anti-rotation, and interlocking mechanisms
• Anti-loosening propeller adapter structure for enhanced flight safety
• Compatible with folding and non-folding propellers

Applications

• High-performance electric fixed-wing UAV cruise propulsion
• VTOL UAV cruise motor
• Electric replacement for combustion engines
